Core Class

The Core class is responsible for managing the main simulation loop, coordinating the actions of the robots, handling synchronization between threads, and updating the arena state. It serves as the central controller for the Epibot simulation, ensuring that the collector and sorter robots operate in harmony and that the simulation progresses smoothly.

class Core {
    public:
        Core(int ac, char **av);
        void simulate();
        ~Core();

    private:
        std::vector<std::string> _map;
        CollectorRobot *_collector;
        SorterRobot *_sorter;
        Ncurses *ncurses;
        std::vector<Waste> _sorterContainer;
        std::mutex _mutex;
        std::condition_variable _cv;
        void sorterRobotExecute();
        void CollectorRobotExecute();
        void drawAndWait();
        bool moveAlongPath(const std::vector<Position>& path, bool collect);
        size_t collectWastes(const std::vector<Position>& wastes, size_t startIndex);
        void moveToSorterRobot();
        bool _collectingFinished;
};

Core Class Attributes

Name	Type	Description
_map	std::vector<std::string>	The arena map, each string is a row of the environment.
_collector	CollectorRobot*	Pointer to the collector robot.
_sorter	SorterRobot*	Pointer to the sorter robot.
ncurses	Ncurses*	Pointer to the Ncurses UI handler.
_sorterContainer	std::vector<Waste>	Container for sorted waste items.
_mutex	std::mutex	Mutex for thread synchronization.
_cv	std::condition_variable	Condition variable for thread coordination.
_collectingFinished	bool	True if waste collection is finished.

---

Core Class Methods

Name	Return Type	Description
Core(int ac, char **av)	Constructor	Initializes the simulation core with command-line arguments.
void simulate()	void	Runs the main simulation loop.
~Core()	Destructor	Cleans up resources and shuts down the simulation.
void sorterRobotExecute()	void	Executes the logic for the sorter robot.
void CollectorRobotExecute()	void	Executes the logic for the collector robot.
void drawAndWait()	void	Renders the simulation state and waits for input or events.
bool moveAlongPath(const std::vector<Position>& path, bool collect)	bool	Moves a robot along a path, optionally collecting waste.
size_t collectWastes(const std::vector<Position>& wastes, size_t startIndex)	size_t	Collects waste from specified positions, starting at startIndex.
void moveToSorterRobot()	void	Moves the collector robot to the sorter robot's position.

---

Deed Explanation of methods

• Constructor
• Public Methods
• Private Methods
• Destructor

---

Constructor

Core::Core(int ac, char **av)
{
    Parser parser(ac, av[1]);
    _map = parser.parseFile();
    ncurses = new Ncurses(_map);
    _collector = new CollectorRobot("RTX5", 3, {1, 1, 0}, _map);
    _collector->setPosition({1, 1, 0}); // Position initiale
    _collector->setStatus(ACTIVE);
    _collectingFinished = false;
    _map[_collector->getPosition().y][_collector->getPosition().x] = 'R';
    _sorter = new SorterRobot("SorterBot");
    _sorter->setPosition({1, 1, 0});
    _sorter->setDestContainerPosition(PLASTIC, {1, 0, 0});
    _sorter->setDestContainerPosition(METAL, {2, 0, 0});
    _sorter->setDestContainerPosition(GLASS, {3, 0, 0});
    _sorter->setDestContainerPosition(ORGANIC, {4, 0, 0});
    _sorter->setStatus(ACTIVE);
}

---

---

Core(int ac, char **av)

Initializes the simulation core by:

• Parsing the input map using Parser
• Creating and positioning the collector robot (CollectorRobot)
• Initializing the sorter robot (SorterRobot) and setting target container positions
• Setting up the ncurses interface

---

Public Methods

void simulate()

void Core::simulate()
{
    std::thread collectorThread([this]() { this->CollectorRobotExecute(); });
    std::thread sorterThread([this]() { this->sorterRobotExecute(); });

    collectorThread.join();
    sorterThread.join();
}

Starts the simulation by spawning two threads:

• Collector robot thread: Handles waste collection.
• Sorter robot thread: Handles waste sorting.

Both threads are joined to ensure clean shutdown at the end of the simulation.

---

Private Methods

void drawAndWait()

void Core::drawAndWait()
{
    ncurses->drawMap(_map);
    std::this_thread::sleep_for(std::chrono::milliseconds(200));
}

Draws the current state of the map and pauses for 200 milliseconds to animate the robots’ movement.

---

bool moveAlongPath(const std::vector<Position>& path, bool collect)

bool Core::moveAlongPath(const std::vector<Position>& path, bool collect)
{
    Position currentPos = _collector->getPosition();

    for (const auto& step : path) {
        int dx = step.x - currentPos.x;
        int dy = step.y - currentPos.y;

        _map[currentPos.y][currentPos.x] = ' ';
        _collector->move(dx, dy, 0);
        currentPos = _collector->getPosition();

        if (collect) {
            char c = _map[currentPos.y][currentPos.x];
            _collector->collect(c, currentPos);
        }

        _map[currentPos.y][currentPos.x] = 'R';
        ncurses->drawMap(_map);
        std::this_thread::sleep_for(std::chrono::milliseconds(100));
    }

    return true;
}

Moves the collector robot along a predefined path.

• If collect is true, the robot will collect waste on the way.
• Updates the map and visual representation via ncurses -> Ncurses.

---

size_t collectWastes(const std::vector<Position>& wastes, size_t startIndex)

size_t Core::collectWastes(const std::vector<Position>& wastes, size_t startIndex)
{
    size_t collected = startIndex;

    for (; collected < wastes.size(); collected++) {
        if (_collector->getContainer().size() >= (size_t)_collector->getMaxCapacity())
            break;

        Position target = wastes[collected];
        auto path = _collector->a_star(target.y, target.x);

        if (!moveAlongPath(path, true))
            break;

        if (_collector->getContainer().size() >= (size_t)_collector->getMaxCapacity())
            break;
    }

    return collected;
}

Attempts to collect wastes starting from a specified index in the list.

• Stops if the collector’s container is full or movement fails.
• Returns the next index to continue from.

---

void moveToSorterRobot()

void Core::moveToSorterRobot()
{
    auto toSorter = _collector->a_star(
        _collector->getSorterRobotPosition().y,
        _collector->getSorterRobotPosition().x
    );

    if (!moveAlongPath(toSorter, false))
        return;
}

Calculates a path from the collector’s current position to the sorter robot, and moves along that path.

---

void sorterRobotExecute()

void Core::sorterRobotExecute()
{
    while (ncurses->isRunning()) {
        std::unique_lock<std::mutex> lock(_mutex);
        _cv.wait(lock, [this] {
            return !_sorterContainer.empty() || _collectingFinished || !ncurses->isRunning();
        });

        if (!ncurses->isRunning())
            break;

        if (_sorterContainer.empty()) {
            if (_collectingFinished) {
                _cv.notify_one();
                break;
            }
            continue;
        }
        auto wastesToSort = _sorterContainer;
        _sorter->setSrcContainer(std::make_pair(Position{2, 2, 0}, _sorterContainer));
        _sorterContainer.clear();
        lock.unlock();

        for (auto& waste : wastesToSort) {
            ncurses->setContainer(wastesToSort);
            std::this_thread::sleep_for(std::chrono::seconds(1));
            _sorter->pickWaste(waste);
            _sorter->sort(waste);
            auto holdingWaste = _sorter->getHoldingWaste();
            _sorter->move(holdingWaste->position.x, holdingWaste->position.y, holdingWaste->position.z);
            ncurses->setPlasticWaste(_sorter->getContainer(PLASTIC));
            ncurses->setMetalWaste(_sorter->getContainer(METAL));
            ncurses->setGlassWaste(_sorter->getContainer(GLASS));
            ncurses->setOrganic(_sorter->getContainer(ORGANIC));
            ncurses->setContainer(_sorter->getSrcContainer());
        }
    }
}

Thread function for the sorter robot.

• Waits for the collector to deposit waste.
• Picks up each waste item, sorts it into the appropriate container based on its type.
• Updates ncurses display with sorted items.

---

void CollectorRobotExecute()

void Core::CollectorRobotExecute()
{
    while (ncurses->isRunning()) {
        drawAndWait();
        auto wastes = _collector->getWastePositions();

        if (wastes.empty() || _collector->getStatus() == INACTIVE) {
            std::this_thread::sleep_for(std::chrono::seconds(3));
            ncurses->drawMap(_map);
            {
                std::unique_lock<std::mutex> lock(_mutex);
                _collectingFinished = true;
                _cv.notify_one();
            }
            {
                std::unique_lock<std::mutex> lock(_mutex);
                _cv.wait(lock, [this] { return _sorterContainer.empty(); });
            }
            ncurses->drawMap(_map);
            ncurses->setisRunning(false);
            break;
        }
        _collector->sortWastesByDistance(_collector->getPosition(), wastes);

        size_t collected = 0;
        while (collected < wastes.size()) {
            collected = collectWastes(wastes, collected);

            moveToSorterRobot();
            {
                std::unique_lock<std::mutex> lock(_mutex);
                _collector->decharge(_sorterContainer);
                _cv.notify_one();
            }
        }
    }
    std::this_thread::sleep_for(std::chrono::seconds(3));
    endwin();
    return;
}

Thread function for the collector robot.

• Continuously scans for wastes.
• Collects them and brings them to the sorter robot.
• Waits for the sorting process to finish before terminating the simulation.

---

Destructor

~Core()

Core::~Core()
{
    if (ncurses)
        delete ncurses;
    if (_collector)
        delete _collector;
    if (_sorter)
        delete _sorter;
}

Cleans up dynamically allocated resources:

• Deletes ncurses interface
• Deletes the collector robot instance
• Deletes the sorter robot instance

---

Notes

• Uses std::mutex and std::condition_variable for thread synchronization between the collector and sorter.
• Simulates autonomous waste management in a 2D environment.
• Relies on A* algorithm for pathfinding.
• Waste types handled: PLASTIC, METAL, GLASS, ORGANIC.
